WR3011GP Wi-Fi 6 AX3000 Dual-Band Router, Qualcomm, Mesh, VPN

WR3011GP

Standard Wi-Fi 6 (802.11ax)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AX3000 (574 + 2474 Mbps = 3047Mbps)
CPU Qualcomm IPQ5000 + QCN6102 + QCA8337, ARM Cortex-A53 Dual-Core 1GHz
RAM 256MB DDR
View all specifications →

5 Years Warranty

Talk via WhatsApp

Specifications

Standard Wi-Fi 6 (802.11ax)
Band Dual-Band (2.4GHz + 5GHz)
Max Speed AX3000 (574 + 2474 Mbps = 3047Mbps)
CPU Qualcomm IPQ5000 + QCN6102 + QCA8337, ARM Cortex-A53 Dual-Core 1GHz
RAM 256MB DDR
Flash 128MB
Antenna 4× 5dBi External (2×2.4G + 2×5G)
Ethernet 1× GbE WAN + 3× GbE LAN
Max Clients 128
Surge Protection 6kV (Common Mode) / 1.5kV (Differential Mode)
Dimensions 188 × 130 × 26–36 mm
Temperature -10°C ~ +45°C
Power DC 12V / 1A

Features

  • Wi-Fi 6 AX3000 on Qualcomm IPQ5000 + QCN6102 enterprise platform
  • 3047Mbps combined throughput (574 + 2474Mbps) with 160MHz bandwidth
  • OFDMA, MU-MIMO, Beamforming, BSS Color for high-density performance
  • Supports up to 128 concurrent clients
  • Mesh and relay mode for scalable multi-room coverage
  • 6kV surge protection, WPA3, VPN, guest WiFi, anti-DDoS
  • 1× GbE WAN + 3× GbE LAN Gigabit ports
  • TR069 remote management for ISP deployment and provisioning

The WR3011GP is a dual-band Wi-Fi 6 AX3000 router built on the Qualcomm IPQ5000 + QCN6102 enterprise platform, delivering 3047Mbps combined throughput (574 + 2474Mbps) with 160MHz bandwidth. Supporting 128 concurrent clients, Mesh networking, WPA3 security, VPN, and 6kV surge protection, it is a premium enterprise-grade wireless router for homes, offices, hospitality venues, and ISP CPE deployments.

Ideal For

  • Homes and apartments requiring premium Wi-Fi 6 performance
  • Offices, co-working spaces, cafes, and retail network deployments
  • ISP CPE programs supplying high-performance home gateways
  • Schools and educational institution wireless networks
  • Smart home and IoT-dense environments requiring stable connectivity

Deployment Advantages

The Qualcomm IPQ5000 platform’s hardware-accelerated OFDMA scheduling provides a measurable throughput and latency advantage over MTK-based solutions in high-client-count environments. The 5GHz 2474Mbps throughput with 160MHz channel width is particularly effective in less congested Wi-Fi environments such as residential and small enterprise deployments.

Mesh and relay mode enables network administrators to deploy multiple WR3011GP units as a cohesive system, sharing a single management interface and SSID. TR069 support allows ISPs to provision, update, and monitor the device remotely — reducing truck rolls and support costs at scale.

OEM/ODM Ready

MossLink offers OEM and ODM customization for this product, including Qualcomm-based custom firmware, ISP UI branding, TR069 integration, antenna configuration, and private-label packaging. Volume pricing is available for ISPs, operators, and enterprise distributors. Contact us to discuss your project requirements.

Frequently Asked Questions

What is the advantage of the Qualcomm IPQ5000 chipset in the WR3011GP?
The Qualcomm IPQ5000 + QCN6102 platform is an enterprise-grade chipset combination that delivers hardware-accelerated OFDMA and MU-MIMO with low latency, making it well suited for high-density deployments. Qualcomm's ecosystem also provides mature driver stability and longer firmware support cycles compared to entry-level chipsets.
What is the maximum wireless throughput of the WR3011GP?
The WR3011GP achieves up to 3047Mbps combined throughput — 573.5Mbps on 2.4GHz and 2474Mbps on 5GHz with 160MHz bandwidth support. This makes it one of the higher-performing AX3000 routers in its class for single-band 5GHz throughput.
What deployment scenarios is the WR3011GP best suited for?
The WR3011GP is designed for homes, offices, cafes, retail stores, co-working spaces, and schools where up to 128 devices need reliable Wi-Fi 6 connectivity. Mesh support, TR069 management, and surge protection make it equally suitable for ISP CPE deployments and small enterprise networks.
Is OEM/ODM customization available for this product?
Yes. MossLink offers full OEM and ODM services for this product, including custom firmware features, hardware modifications, enclosure branding, and private-label packaging. Minimum order quantities apply. Contact us to discuss your project requirements.
